Fiuu’s Offline Payment API (OPA) allows merchants to generate dynamic QR codes for the customer to scan using mobile device installed app (e-wallet and mobile banking app) to perform payment. To ensure a smooth payment experience and minimize failures, follow these guidelines when using time-sensitive dynamic QR codes (typically valid for 10 minutes):

QR Code Displayed Promptly

Generate and display the QR code immediately after the customer confirms the payment amount.
Avoid unnecessary delays (e.g., waiting for additional user input) before showing the QR code.

Countdown Time is Clearly Shown

Display a visible countdown timer (e.g., “QR code expires in 09:59”) near the QR code.
This creates urgency and informs customers that the code is temporary.

Provide Clear Instructions

Add a short message like: “Scan this QR code using your e-wallet or mobile banking app within 10 minutes.”
If possible, include logos of supported wallets for quick recognition.

Handle Expiry Gracefully

When the QR code expires:

o Hide or gray out the expired QR code.

o Show a message: “This QR code has expired. Please request a new one.”

o Provide a ‘Regenerate QR Code’ button for easy retry.

Optimize For Different Channels

Website: Ensure the QR code is large and centered for easy scanning.
Mobile App: Use full-screen or modal display for better visibility.
Self-Service Kiosk / Terminal: Position the QR code at eye level and ensure good screen brightness.
Vending Machine: Use a high-contrast display and avoid glare.

Avoid Printing Dynamic QR Codes

Do not print dynamic QR codes on receipts or paper, as they will expire quickly.
For printed materials, use static QR codes linked to your payment page instead.

Monitor & Retry

Track QR code generation and payment status.
If a payment is not completed within the validity period, automatically prompt the user to regenerate a new QR code.
If first attempt failed, advise user to try with other e-wallet / online banking app.

Example of UI Flow

flowchart LR
    A[Customer selects items → Confirms payment amount] --> B[System calls Fiuu OPA → Receives QR code content or image link]
    B --> C[Display QR code + countdown timer + instructions]
    C --> D[On expiry → Show “Expired” message + Regenerate option]

Do's & Don'ts for Handling Merchant-Presented Dynamic QR Codes
